ISATEST

ISA range of portable test equipment plays an important part in our power and energy management system solutions.

With the expertise and technology that ISA offers, we are able to assist our customers in maintaining the reliability and quality of their electrical system assets.

This helps our customer to reduce their electrical equipment maintenance costs.

All ISA Test and Measurement Instruments have been designed to be used in severe environment such as high voltage substations and heavy industry plants.

All ISA Test Instruments are developed, designed and constructed to comply with the IEC, CE and the most used international standards. Each test set data-sheet describes in detail the international applicable standard ISA comply with.

ISA manufacturing and development facilities are certified to the full operational requirements of the ISO 9001 quality standard since 1994 and ISO 9001 – VISION 2000 since year 2000.

ISA is constantly improving its quality management system by focusing more and more on products reliability and ruggedness.

DRTS 33

DRTS 33 - THE NEW GENERATION OF TEST EQUIPMENT FOR PROTECTIVE RELAYS, ENERGY METERS, TRANSDUCERS AND POWER QUALITY METERS

This advanced secondary injection relay test system and power system simulator is designed to satisfy all the needs related to commissioning and maintaining substations and to testing protection relays, energy meters, transducers and power quality meters.

Local control with color display
Simultaneously available: 3 Current and 3 Voltage plus 1 battery simulator outputs.
High current outputs: 3 x 32 A, 1 x 96 A
High power outputs: 3 x 430 VA, 1 x 1000 VA
Voltage outputs: 3 x 300V at 100 VA
High accuracy outputs: better than 0.05%

Optional IEC 61850 protocol interface
USB and Ethernet interface
Pen drive interface
Optional internal GPS and IRIG-B interface for end-to-end tests
Optional PC control using TDMS – Advanced Test and Data Management software
Complete library of relays from the major manufacturers.

DRTS 33 DATASHEET DOWNLOAD PRODUCT PDF

DRTS 3PLUS

DRTS 3PLUS -AUTOMATIC THREE-PHASE RELAY TEST SET

This power system simulator is designed to give the highest accuracy when testing and calibrating protective relays, energy meter, transducer and power quality devices. This diagnostic and calibration equipment is the perfect solution to perform automatic testing on protection devices.

Multi-tasking relay test equipment designed for testing protection relays, energy meters, transducers
Output: 3Ã—15 A (100 VA); 4Ã—300 V (85 VA); 1Ã—260 V DC
High accuracy: better than 0,05%
Analog measurement inputs

IEC 61850 communication Protocol interface
USB and RS232 port
Controlled by PC laptop or local control by PDA
Lightweight: 18 kg

DRTS 3PLUS DATASHEET DOWNLOAD LINK

TDMS

TDMS - TEST AND DATA MANAGEMENT SOFTWARE

TDMS software is also a powerful database. It allows to create an electrical network with substations, feeders and the majority of electrical apparatus, such as:
